The Guanshentai One-Way Valve Automatic Ultrasonic Welding and Assembly Machine is an integrated system specifically designed for the precision assembly and ultrasonic welding of one-way valve compo
The Guanshentai One-Way Valve Automatic Ultrasonic Welding and Assembly Machine is an integrated system specifically designed for the precision assembly and ultrasonic welding of one-way valve components. It combines automatic feeding (for upper components, lower components, and valve core assemblies), precision positioning and assembly, lifting and flipping, ultrasonic welding, and automatic unloading into a single unit. The entire line automates the process from bulk parts to finished welded valves, achieving a production rate of up to 600 units per hour and effectively replacing traditional manual assembly and welding methods.
Key Advantages:
Integrated Design: The machine combines assembly and welding functions into one unit. A synchronous transfer mechanism ensures efficient flow between stations, sequentially completing key processes such as inserting the valve core into the upper component, flipping the upper component to mate with the lower component, and ultrasonic welding for a hermetic seal. This eliminates the need for multiple machines performing segmented tasks, significantly shortening the production cycle time.
High-Precision Ultrasonic Welding: An ultrasonic welding mechanism fuses the connection point between the upper and lower valve components. Welding energy is highly concentrated at the interface (completed within milliseconds), resulting in a minimal heat-affected zone that does not impact precision moving parts like the valve core or spring. The weld seam is dense and uniform, meeting high-standard sealing requirements and eliminating risks associated with adhesive bonding, such as curing shrinkage or internal leakage.
Multi-Component Automatic Feeding System: Equipped with independent hoppers and linear vibratory tracks for upper components, lower components, and valve cores, the system automatically sorts and conveys parts to designated stations. Pick-and-place mechanisms and grippers work in tandem to ensure precise assembly without manual intervention.
Precision Assembly with Lifting and Flipping: A lifting-and-flipping mechanism precisely rotates the upper component (containing the valve core) by 180° before mating it with the lower component. The flipping angle and positioning are highly accurate, ensuring coaxial alignment and assembly consistency between the upper and lower components.
Broad Material Compatibility: The machine supports the welding of one-way valve components made from various thermoplastic engineering plastics, such as PP, PE, PC, and PA. Welding horns and fixtures can be custom-designed based on the valve structure to accommodate different product specifications.
Clean and Safe Design: The machine features an enclosed protective structure with a clean, controllable welding zone, meeting the production standards for medical device cleanrooms. It is equipped with light curtain safety guards and emergency stop devices to ensure operator safety.
Application Scenarios:
Ideally suited for the large-scale, standardized automated assembly and welding of components across various sectors, including medical devices (check valves for medical nebulizers, respiratory therapy consumables, and IV sets), fluid control equipment (micro gas control valves and fluid directional valves), automotive parts (fuel system and A/C line check valves), and home appliances/sanitary ware (water purifier check valves and water pump non-return valves). With its efficient, precise, and clean automated performance, the Guanshentai automatic ultrasonic welding and assembly machine empowers valve manufacturers to upgrade to fully automated, integrated production—from individual parts to finished products.
Product Details.
Model:GST-YYG201A
Voltage:220VAC
Power:2KW
Capacity:600pcs/H
Size:280*250*220CM
Weight:1000KG
Accessories:Xinjie
Voltage and Frequency:50Hz±2
PLC:Sanling
Display:Willenton
Frequency converter: Huichuan
Vibrating disk: Chuangyou
CCD vision: Keen
Customized Support: Yes
