The edible oil automatic filling machine is an automated packaging equipment designed for edible vegetable oil liquids. It can automatically fill oil into plastic bottles, glass bottles, iron barrels, edible oil pots or ton barrels according to the set capacity, and realize a series of operations such as automatic bottle sorting, weighing, filling, capping, labeling, and coding. The design of the equipment fully considers the viscosity, cleaning requirements and filling speed of the oil products, and is an ideal choice for edible oil production enterprises to achieve large-scale, standardized and modern packaging.
1. Main components and functions of the equipment
A mature edible oil automatic filling machine system usually includes the following key modules:
Automatic bottle sorting system: automatically sort out the messy empty bottles and send them to the filling station in an orderly manner.
Weighing or flow meter filling system: The mainstream filling methods include weighing and flow meter. The weighing type is suitable for packaging with high precision requirements, while the flow meter type has a fast filling speed and convenient maintenance.
Anti-drip filling valve: The anti-drip device is used to prevent oil from contaminating the bottle mouth and conveyor line, ensuring the neat appearance of the product.
Automatic capping system: automatically delivers the bottle cap to the bottle mouth and tightens it, supporting a variety of bottle cap types.
Human-machine interface and PLC control system: the operator can set parameters such as filling weight and speed through the touch screen, automatically alarm and prompt fault information.
Conveying and detection system: equipped with conveyor belt, liquid level detection, empty bottle detection and weight verification to ensure that each bottle is filled correctly.
2. Advantages of automatic edible oil filling machine
High-efficiency production: dozens to hundreds of bottles can be filled per minute, suitable for continuous operation of large and medium-sized production lines, significantly improving production capacity.
Precise and stable: high filling accuracy, the error is generally controlled within ±0.2%, ensuring that each bottle of oil reaches the standard net content and reducing customer complaints.
Clean and hygienic, in line with food standards: parts in contact with oil products are made of 304 or 316 stainless steel, meet food-grade hygiene requirements, and support CIP cleaning system.
Strong compatibility with multiple specifications: By replacing the filling head or adjusting the parameters, it can adapt to various specifications of packaging such as 1L, 2L, 5L, 10L and even 20L.
Save labor costs: High degree of automation, greatly reducing manual operation and intervention, reducing labor costs, and improving the level of factory intelligence.
Intelligent control and data management: It can be connected to the MES system to realize remote monitoring, production statistics, quality tracking and other functions, helping enterprises to transform digitally.
The automatic edible oil filling machine not only plays an important role in improving filling efficiency and ensuring product consistency, but is also an essential equipment for enterprises to move towards automated and intelligent production. With its advantages of precision, cleanliness, safety and efficiency, it fully meets the current market's high standards for edible oil packaging.
