Description of O-type sealing gasket automatic assembly machine:
The machine automatically assembles O-rings into nuts, including internal and external thread nuts. By replacing replaceable modules, one machine can be compatible with nuts of various sizes. It consists of an automatic feeding mechanism, an O-ring assembly mechanism, an NG product detector, a leak detection module, and a qualified product unloading mechanism.
Features of O-type sealing gasket automatic assembly machine:
1. Suitable for various O-ring nuts, including internal and external thread nuts;
2. By replacing replaceable modules, one machine is compatible with various screw caps;
3. Supports automatic detection and removal of defective products such as loose O-rings and deviations;
4. Equipped with leak detection module;
5. Made of high-quality 304 stainless steel, suitable for industrial production environment;
6. Adopts PLC module, stepless speed variable frequency regulator & servo motor driver;
7. Automatic fault alarm, touch screen display solution.
model number: GST-WJ012A
sizes: L1670*W1290*H2121(mm)
production capacities: 1440pcs/h
power (output): 220V/50HZ 20A 5KW
Customized Support: Yes
