Automatic Liquid Quantitative Filling Machine | Fully Automatic Precision Metering Filling Equipment | Manufacturer of Automated Filling Equipment

　　The Guanshentai automatic liquid quantitative filling machine utilizes high-precision volumetric metering technology based on piston or Roots pumps, fundamentally eliminating the accuracy degradation caused by wear and tear typical of traditional flow meters. It maintains a filling accuracy within ±0.3% and offers an adjustable single-fill range of 50ml to 10L. Equipped with anti-drip one-way valve nozzles and liquid collection trays, the machine ensures no residue remains on the bottle mouth and prevents contamination of the bottle exterior.

　　Core Advantages:

　　Superior Precision: Employs a dual-positioning system combining mechanical hard stops and photoelectric sensors to ensure consistent metering from the first to the last bottle of every batch, eliminating the need for frequent recalibration.

　　Robust Materials: Wetted parts are constructed from SUS316L stainless steel, offering high corrosion and heat resistance; the machine handles liquids with pH levels ranging from 2 to 12 and boasts a service life of over ten years.

　　Flexible Production Switching: Features detachable quick-connect interfaces, allowing tool-free replacement of material cylinders, seals, and filling nozzles. This design ensures thorough cleaning with no dead zones and enables product changeovers in just 5 minutes.

　　Energy Efficiency & Noise Reduction: Utilizes servo motor direct-drive technology instead of traditional pneumatic systems, reducing energy consumption by 30% and keeping operating noise below 65 decibels to meet workshop environmental standards.

　　Application Scenarios:

　　Widely used across industries such as food and beverage (fruit juice, cooking oil, honey), personal care and household chemicals (shampoo, laundry detergent, fabric softener), pharmaceuticals (syrups, oral solutions, disinfectants), and industrial chemicals (lubricating oil, antifreeze, water-based coatings). Whether for flexible production lines handling small batches of diverse products or for continuous, large-scale 24-hour operations, Guanshentai filling machines deliver stable performance, making them a reliable choice for manufacturers aiming to standardize their filling processes.

　　Technical parameters:

　　Model Number: GST-SWYP005A

　　Filling capacity: 25-250ml,50-500ml,150-1000ml,500-2500ml(different specifications can be ordered).

　　Canning efficiency: 25-40 bottles/minute (6 heads in the range of 50-500ml).

　　Canning precision: <±1%.

　　Power supply: 220V 50HZ.

　　Air pressure: 4-6MPa.

　　Overall dimension: 2500*900*2000mm.

　　Quality: 650KG.

　　Customized Support: Yes
