The automatic assembly machine for dental mirrors is designed for the automated assembly of disposable dental mirrors (comprising components such as the mirror head, handle, connector, and protectiv
The automatic assembly machine for dental mirrors is designed for the automated assembly of disposable dental mirrors (comprising components such as the mirror head, handle, connector, and protective sleeve). It integrates multi-channel automatic feeding, precision alignment and press-fitting, threaded fastening or ultrasonic welding, in-line inspection, and finished product sorting. This enables a fully automated, closed-loop process—transforming loose components into finished mirrors—while strictly meeting the medical device industry's rigorous standards for high precision, cleanliness, and traceability.
The equipment utilizes multiple precision vibratory bowls or robotic arms to feed components such as mirror heads, handles, and connectors. Using a high-precision rotary table or linear slide, it sequentially performs mirror orientation detection and positioning, handle angle calibration, mirror press-fitting or screw-fastening, finished product inspection, and sorting—all without manual intervention. A single operator can monitor multiple assembly lines simultaneously, significantly reducing staffing requirements and labor intensity.
Built with a high-strength cast frame and independent servo drive systems, and equipped with vision recognition and precision positioning modules, the machine achieves a repeatability of ±0.05 mm. This ensures high consistency in mirror assembly angles, concentricity, and tightening torque across every unit. Critical press-fitting and fastening stations feature high-precision torque control systems and pressure sensors to prevent overtightening or undertightening. The machine supports stable, continuous 24/7 operation with an assembly defect rate of less than 0.1%, guaranteeing consistent product quality across batches.
Equipped with a PLC and industrial touchscreen, the system stores assembly parameters (such as tightening torque, press-fit stroke, and welding time) for hundreds of mirror specifications (mirror size, handle shape, connection type), allowing for rapid product changeovers with a single command. Integrated vision inspection and real-time torque monitoring systems automatically detect defects—such as missing mirrors, improper assembly, or stripped threads—triggering automatic rejection and audio-visual alarms. Additionally, the system supports production data storage and MES integration, ensuring full traceability of the assembly process.
With an assembly speed of up to 30–100 units per minute (depending on specifications and assembly method), a single machine easily exceeds a daily output of 50,000 units—delivering 5 to 10 times the efficiency of manual assembly. Featuring a multi-station parallel or rotary synchronous assembly design, the system drastically shortens production cycle times while significantly reducing the risk of microbial contamination associated with human handling, ultimately cutting overall operating costs by more than 50%.
Powered by precision servo control and intelligent in-line inspection, this automatic dental mirror assembly machine ensures that the bond between the mirror lens and handle meets the rigorous standards required for clinical use. Leave behind the inconsistency and inefficiency of manual assembly; choose this solution to ensure your dental mirrors deliver consistent, high quality as they serve the front lines of global dental care.
Technical parameters:
Model Number: GST-BC004
Sizes: L2232*W2122*H1800(mm)
Production Capacities: 150-200pcs/min
Power (Output): 3KW,220V
Weight:1000KG
Customized Support: Yes
